Front Forks Peload Adjuster 33mm/ Black
Front Forks Peload Adjuster 33mm/ Black
| Code： | 690E05BK33 |
| Scale： | |
| Class： | FOR ALL MOTOR MODELS |
Available front forks inner tube for 33mm, metric thread size x pitch: m28*1.0
Not available for original front forks 33mm with c-retaining ring.
Two rollers setting for different weight riders to adjust.
Roll 0~10 for adjusting.
Total compression stroke 12.5mm; each roll for 1.25mm
Adjusting suggest:
1 person riding (roll 0~5);
2 people riding (roll 6~10)
※ Available front forks inner tube for 33mm, metric thread size x pitch: M28*1.0
※ Not available for original front forks 33mm with C-retaining ring.
PHOTO FOR REFERENCE. REAL PARTS FOR THAT YOU RECEIVE
PICTURE/DIAGRAM FOR REFERENCE ONLY, PLEASE SEE SAMPLE FOR ACTUAL SIZE
